Tools / Drills / Overview of Drills / Coated Cemented Carbide PVD

  • KDG304

    ISO: P10 — P20, K10 — K20

    PVD coated carbide substrate for machining caststeel and cast iron. Optimised toughness for high feeds.

  • KDG305

    ISO: M10 — M20, S10 — S20

    PVD coated carbide substrate for machining stainless steel and HRSA. High process reliability due to improved wear resistance.

  • KDG303

    ISO: P10 — P20, M10 — M20, K10 — K20

    PVD coated P10–P20/M10–M20/K10–K20 carbide grade for steel, stainless steel and cast iron. Good wear resistance and toughness for a wide application field.

YBG212

ISO: P25 — P35, M25 — M40

PVD coated M25–M40/P25–P35 carbide substrate for steel and stainless steel. Especially for inner insert at drilling operation.

YB9320

ISO: P10 — P30, M10 — M25

PVD multilayer coated M10–M25/P10–P30 carbide substrate for finishing to medium application of stainless steel, super alloy and steel (grooving/milling). Optimized coating stability for higher wear resistance and thermal stability in a wide application field.

YBG205

ISO: P10 — P30, M20 — M45, S15 — S25

PVD multilayer coated M20–M40/S15–S25/P10–P30 carbide substrate for finishing to medium application of stainless steel, super alloy and steel (milling). Good wear resistance and thermal stability in a wide application field.

YBS203

ISO: S15 — S25

Turning and milling grades for processing heat-resistant materials. A special carbon substrate and the latest PVD coating technology enable a very good wear behaviour, high fracture toughness and high thermal stability.

YBG202

ISO: P10 — P30, M10 — M25

PVD coated M10–M25/P10–P30 carbide substrate for finishing to medium application of stainless steel and steel (milling). Good wear resistance in a wide application field.
